High-speed precision presses
HOWFIT DDL-220T
- Nominal force
- 2200 kN
- Shut-height adjustment
- 50 mm
- Slide dimensions
- 1900×700 mm
MOD-1888
High-speed precision presses · MOD-1886
High-speed precision presses — HOWFIT H-360T
HOWFIT Science and Technology Co., Ltd.
Nominal force: 3600 kN; Shut-height adjustment: 50 mm; Slide dimensions: 2400×900 mm
This page lists confirmed manufacturer data. The scope of supply and unlisted parameters will be clarified when preparing the quotation.
Request price and configuration ↗Price, availability and lead time are not stated. They will be confirmed in the quotation.
| Nominal force | 3600 kN |
|---|---|
| Shut-height adjustment | 50 mm |
| Slide dimensions | 2400×900 mm |
| Bolster dimensions | 2400×1000 mm |
| Bolster opening | 1900×300 mm |
| Main motor power | 75 4P kW |
| Stroke length | 30 mm |
| Maximum strokes per minute | 400 SPM |
| Minimum strokes per minute | 150 SPM |
| Shut height | 400-450 mm |
This page lists confirmed manufacturer data. The scope of supply and unlisted parameters will be clarified when preparing the quotation.
Other models in this category
A shared category does not imply technical interchangeability.
High-speed precision presses
HOWFIT DDH-300T
- Nominal force
- 3000 kN
- Shut-height adjustment
- 50 mm
- Slide dimensions
- 2300×900 mm
MOD-1894
High-speed precision presses
HOWFIT HSF-5T
- Nominal force
- 50 kN
- Shut-height adjustment
- 50 mm
- Slide dimensions
- 340W×310D (W: width; D: depth) mm
MOD-1911
